单N-MOS

PE8126HM1 DFN3x3-8L

    PE8126HM1是VDS>12V,ID=26A,RDS(ON)<3.2mΩ,@VGS=4.5V,RDS(ON)<3.5mΩ,@VGS=3.8V,RDS(ON)<4.0mΩ,@VGS=3.1V,RDS(ON)<5.2mΩ,@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.
    PE8126HM1的丝印是8126HM。PE8126HM1提供DFN3x3-8L封装.
    The PE8126HM1 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
    PE8126HM1概述:
        PE8126HM1是VDS>12V,ID=26A,RDS(ON)<3.2mΩ,@VGS=4.5V,RDS(ON)<3.5mΩ,@VGS=3.8V,RDS(ON)<4.0mΩ,@VGS=3.1V,RDS(ON)<5.2mΩ,@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE8126HM1的丝印是8126HM。PE8126HM1提供DFN3x3-8L封装.
        The PE8126HM1 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.

    PE8126HM1特性:
    VDS > 12V, ID = 26A
    RDS(ON) < 3.2mΩ @ VGS=4.5V
    RDS(ON) < 3.5mΩ @VGS=3.8V
    RDS(ON) < 4.0mΩ@VGS=3.1V
    RDS(ON) < 5.2mΩ @VGS=2.5V
    ESD Rating: 4000V HBM
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE8126HM1应用:
    PWM applications
    Load switch
    Power management

    PE8126HM1典型应用及引脚:
