The ME6231 series are high accuracy, CMOS LDO Voltage Regulators, offering low power, high ripple rejection ratio and low dropout. the ME6231 series is ideal for today’s cutting edge mobile phone. Internally the ME6231 includes a reference voltage source, error amplifiers, driver transistors, current limiters and phase compensators. The ME6231’s current limiters‘ foldback circuit also operates as a short protect for the output current limiter and the output pin. The ME6231 series is also fully compatible with low ESR ceramic capacitors, reducing cost and improving output stability. This high level of output stability is maintained even during frequent load fluctuations, due to the excellent transient response performance and high PSRR achieved across a broad range of frequencies. The CE function allows the output of regulator to be turned off, resulting in greatly reduced power consumption.

Maximum Output Current: 500mA（VIN＝4.3V,VOUT＝3.3V）

Dropout Voltage: 125mV@IOUT =100mA（VOUT＝3.3V）

Operating Voltage Range: 3V~18V

Output Voltage Range: 1.6V~5.0V

Highly Accuracy: ±1％

Low Power Consumption: 1.8uA（TYP.）

Standby Current: 0 uA（TYP.）

High Ripple Rejection: 65dB@1KHz（ME6231C33）

Line Regulation: 0.035％/V（TYP.）

Built-in temperature protection and current limiting protection

Mobile phones

Cordless phones, radio communication equipment

Portable games

Cameras, Video cameras

Reference voltage sources

Battery powered equipment

3-pin SOT23-3、SOT89-3

5-pin SOT23-5

Note: Ceramic capacitor with X7R and X5R offer improved voltage and temperature coefficients.10uF Ceramic

capacitor is recommended for excellent load transient response and linne transient response.
