CST80P03 TO252
CST80P03是-30V，6.0mΩ，-80A的P-MOS，提供TO252封装。
The CST80P03 is the high cell density trenched P-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST80P03 meet the RoHS and Gree
The CST80P03 is the high cell density trenched P-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST80P03 meet the RoHS and Gree
CST80P03 Description：
CST80P03是-30V，6.0mΩ，-80A的P-MOS，提供TO252封装。
The CST80P03 is the high cell density trenched P-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST80P03 meet the RoHS and Gree Product requirement 100% EAS guaranteed with full function reliability approved.
CST80P03 Features：
100% EAS Guaranteed
Green Device Available
Super Low Gate Charge
Excellent CdV/dt effect decline
Advanced high cell density Trench technology
CST80P03 Product Summary：
BVDSS | RDSON | ID |
-30V | 6.0mΩ | -80A |
CST80P03 Test Circuit：
