The TX6251 series is a group of positive voltage output, three-pin regulators, that provide a high current even when the input/output voltage differential is small.Low power consumption and high accuracy is achieved through CMOS and laser trimming technologies.The TX6251 consists of a high-precision voltage reference, an error amplification circuit, and a current limited output driver.Transient response to load variations have improved in comparison to the existing series.

    SOT89-3 SOT89-5 TO92 SOT223 TO252 TO263 and TO220 packages are available.

Low voltage drop: 0.06V@100mA l High input voltage: 10V

Low temperature coefficient

Low Quiescent Current: 25uA at 5.0V

Output voltage accuracy: tolerance ±1%

Battery-powered equipment

Hand-Hold Equipment

GRS Receivers

Wireless LAN
