CST30P03D PDFN3333-8L
CST30P03D是BVDSS=-30V,RDSON=15mΩ,ID=-30A的快速切换Mosfets.提供PDFN3333-8L封装。
The CST30P03D is the high cell density trenched P-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
TheCST3
The CST30P03D is the high cell density trenched P-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
TheCST3
CST30P03D Description/描述:
CST30P03D是BVDSS=-30V,RDSON=15mΩ,ID=-30A的快速切换Mosfets.提供PDFN3333-8L封装。
The CST30P03D is the high cell density trenched P-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
TheCST30P03D meet the RoHS and Gree Product requirement 100% EAS guaranteed with full function reliability approved.
CST30P03D Features/特性:
100% EAS Guaranteed
Green Device Available
Super Low Gate Charge
Excellent CdV/dt effect decline
Advanced high cell density Trench technology
CST30P03D Product Summary/产品概览：
BVDSS | RDSON | ID |
-30V | 15mΩ | -30A |
CST30P03D Pin Configuration/引脚配置:
CST30P03D Test Circuit/测试电路：
