CST20N03D PDFN3*3
CST20N03D是VDS=30V,ID=20A的N通道Mosfets。
The CST20N03D is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST20N03D meet the RoHS and Green P
The CST20N03D is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST20N03D meet the RoHS and Green P
CST20N03D Description/概述：
CST20N03D是VDS=30V,ID=20A的N通道Mosfets。
The CST20N03D is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST20N03D meet the RoHS and Green Product requirement, 100% EAS guaranteed with full function reliability approved.
CST20N03D Features/特性：
Super Low Gate Charge
100% EAS Guaranteed
Green Device Available
Excellent CdV/dt effect decline
Advanced high cell density Trench technology
CST20N03D Product Summary/产品概览:
BVDSS | RDSON | ID |
30V | 15mΩ | 20A |
CST20N03D PDFN3*3 Pin Configuration/引脚配置:
.jpg)
CST20N03D Test Circuit/测试电路:
