MXD035N02 TO-252
MXD035N02是VDS=20V,ID=100A,RDS(ON)(Typ.)=4.7mΩ@VGS=2.5V,RDS(ON)(Typ.)=3.5mΩ@VGS=4.5V的N沟道Mosfet。提供TO-252封装。
The MXD035N02 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.
The MXD035N02 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.
MXD035N02 Description/概述：
MXD035N02是VDS=20V,ID=100A,RDS(ON)(Typ.)=4.7mΩ@VGS=2.5V,RDS(ON)(Typ.)=3.5mΩ@VGS=4.5V的N沟道Mosfet。提供TO-252封装。
MXD035N02是VDS=20V,ID=100A,RDS(ON)(Typ.)=4.7mΩ@VGS=2.5V,RDS(ON)(Typ.)=3.5mΩ@VGS=4.5V的N沟道Mosfet。提供TO-252封装。
The MXD035N02 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a wide variety of applications.
MXD035N02 Features/特性：
VDS=20V, ID=100A
RDS(ON)(Typ.)=4.7mΩ @ VGS=2.5V
RDS(ON)(Typ.)=3.5mΩ @ VGS=4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
MXD035N02 Applications/应用：
Battery Protection
Load switch
Power management
MXD035N02 Pin Configuration/引脚配置:
MXD035N02 Ordering Information/订购信息：
Device | Marking | Storage Temperature | Package | Devices Per Reel |
MXD035N02 | 035N02 | -55°C to 150°C | TO-252-2L | 2500 |
MXD035N02 Test Circuit/测试电路：
