CST4030F DFN5060-8L
CST4030F是N-Ch：BVDSS=40V,RDSON=13.5mΩ,ID=30A:P-Ch：BVDSS=-40V,RDSON=25mΩ,ID=-30A的N+P双沟道快速切换Mosfets。提供PDFN5060-8L封装
CST4030F Description/描述:
CST4030F是N-Ch：BVDSS=40V,RDSON=13.5mΩ,ID=30A:P-Ch：BVDSS=-40V,RDSON=25mΩ,ID=-30A的N+P双沟道快速切换Mosfets。提供PDFN5060-8L封装。
The CST4030F is the high performance complementary N-ch and P-ch MOSFETs with high cell density, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST4030F meet the RoHS and Green Product requirement 100% EAS guaranteed with full function reliability approved.
CST4030F Features/特性:
100% EAS Guaranteed
Green Device Available
Super Low Gate Charge
Excellent CdV/dt effect decline
Advanced high cell density Trench technology
CST4030F Product Summary/产品概览：
BVDSS | RDSON | ID |
40V | 13.5mΩ | 30A |
-40V | 25mΩ | -30A |
CST4030F PDFN5060-8L Pin Configuration/引脚配置：
