NY8 Series — 8-bit OTP/MTP MCU for Home Appliance
| P/N | I/O | XTAL | OTPx14 | RAMx8 | LIR | 12-bit ADC | CMP | Ext. INT | LVD | Remarks | Package | |
| NY8A050D | 6 | - | 0.5K | 32 | - | - | - | - | 1 | - | Consumer | SOT23-6, SOP8 |
| NY8A051B | 6 | - | 1K | 48 | 1x8b/1 | - | - | - | 1 | - | High-EFT | SOT23-6, SOP8, DIP8 |
| NY8A051D | 6 | - | 1K | 48 | 1x8b/1 | - | - | - | 1 | - | Consumer | SOT23-6, SOP8, DIP8 |
| NY8A051E | 6 | V | 1K | 48 | 1x8b/1 | - | - | - | 1 | - | Consumer | SOT23-6, SOP8, DIP8 |
| NY8A051F | 6 | 1K | 48 | 1x8b/1 | - | - | - | 1 | V | Consumer | SOT23-6, SOP8, DIP8 | |
| NY8A051G | 6 | V | 1K | 48 | 1x8b/1 | - | - | - | 1 | - | Consumer | SOT23-6, SOP8 |
| NY8A053B | 12 | V | 1K | 64 | 1x8b/1 | V | - | - | 1 | - | High-EFT | SOP14, DIP14 |
| NY8A053D | 12 | V | 1K | 64 | 1x8b/1 | - | - | - | 1 | - | Consumer | SOP8, SOP14, DIP14 |
| NY8A054A | 14 | V | 2K | 128 | 5x10b/2 | V | - | 1 | 2 | V | High-EFT | SOP16 |
| NY8A054D | 14 | V | 2K | 128 | 5x10b/2 | - | - | 1 | 2 | V | Consumer | SOP8, SOP16 |
| NY8A056A | 16 | V | 1K | 96 | 2x8b/2 | V | - | 1 | 1 | - | High-EFT | SOP16, SOP18, DIP18, SSOP20 |
| NY8B062A | 14 | V | 2K | 128 | 3x10b/3 | V | 11+1 | 1 | 2 | V | High-EFT | SOP8, SOP14, SOP16 |
| NY8B062B | 14 | V | 2K | 128 | 3x10b/3 | V | 11+1 | 1 | 2 | V | High-EFT | SOP8, SOP14, SOP16 |
| NY8B062D | 14 | V | 2K | 128 | 3x10b/3 | - | 11+1 | 1 | 2 | V | Consumer | SOP8, SOP14, SOP16 |
| NY8B071A | 12 | V | 1K | 96 | 3x10b/3 | V | 6-ch | 1 | 2 | V | High-EFT | SOP8, SOP14, DIP14 |
| NY8B072A | 18 | V | 2K | 128 | 3x10b/3 | V | 12+1 | 1 | 3 | V | High-EFT | SOP20, DIP20 |
| P/N | I/O | XTAL | MTPx14 | EE | PWM/Buzzer | LIR | 12-bit ADC | CMP | Ext. INT | LVD | Remarks | Package |
| NY8AE51D | 6 | - | 1K | 64 | 64 Byte | 3x10b/1 | - | - | 1 | V | Consumer | SOT23-6, SOP8 |
| NY8BM72A | 18 | V | 2K | 128 | - | 3x10b/3 | 12+2-ch | 1 | 3 | V | High-EFT | SOP20 |
Remarks:
1x8b/1
5x10b/2
1. Operating Voltage = 2.0~5.5V, up to 20MHz, Dual Clock, WDT, LVR .
2. NY8A: GPIO, NY8B: ADC, NY8AE: MTP.
3. NY8xxxA/B are High-EFT version with Noise Filter. NY8xxxC/D/E are Low-Eft version without Noise Fliter.
4. LIR: 340mA Large sink current IR output.
5. CMP: Comparator.
6. EE: EEPROM.
