PE8203概述：
PE8203是VDS=18V,ID=6.5A，RDS(ON)<20mΩ，@VGS=4.5V，RDS(ON)<21mΩ，@VGS=3.8V，RDS(ON)<28mΩ，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE8203的丝印是8203.PE8203提供SOT-23-6L封装.
The PE8203 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE8203特性：
VDS = 18V, ID = 6.5A
RDS(ON) < 20mΩ @ VGS=4.5V
RDS(ON) < 21mΩ @VGS=3.8V
RDS(ON) < 28mΩ @VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE8203应用：
Battery Protection
Load switch
PE8203典型应用及引脚：
