The XYT2112-XX is low power consumption very low 2uA ground current, high performance 150mA LDO . The family uses an advanced CMOS process and a PMOSFET pass device to achieve fast start-up, with high output voltage accuracy . The XYT2112-XX is stable with a 10.0μF ceramic output capacitor, and uses a precision voltage reference and feedback loop to achieve a worst-case accuracy of 1% over all load, line, process, and temperature variations. It is fully specified from TJ =–40℃ to +125℃ and is offered in a SOT89-3 ，SOT23-3 package.
