N+P-MOS

MX4606 SOP8

    MX4606是N-Channel:VDS=30V,ID=6A,RDS(ON)(Typ.)20mΩ,@VGS=10V,RDS(ON)(Typ.)29mΩ,@VGS =4.5V.P-Channel: VDS=-30V,ID=-5A,RDS(ON)(Typ.)38mΩ,@VGS=-10V,RDS(ON)(Typ.)58mΩ,@VGS=-4.5V的30V,Complementary MOSFET.
    MX4606提供SOP-8封装.
    Ther MX4606 uses advanced trench technology to Provi deexcellent RDS(ON), low gate charge.This device may be used to form a level shifted high side switch, and for a host of other application.
    MX4606概述:
        MX4606是N-Channel:VDS=30V,ID=6A,RDS(ON)(Typ.)20mΩ,@VGS=10V,RDS(ON)(Typ.)29mΩ,@VGS =4.5V.P-Channel: VDS=-30V,ID=-5A,RDS(ON)(Typ.)38mΩ,@VGS=-10V,RDS(ON)(Typ.)58mΩ,@VGS=-4.5V的30V,Complementary MOSFET.
        MX4606提供SOP-8封装.
        Ther MX4606 uses advanced trench technology to Provi deexcellent RDS(ON), low gate charge.This device may be used to form a level shifted high side switch, and for a host of other application.

    MX4606特性:
    N-Channel
    VDS = 30V,ID =6A
    RDS(ON) (Typ.)20mΩ @ VGS =10V
    RDS(ON) (Typ.)29mΩ @ VGS =4.5V
    P-Channel:
    VDS = -30V,ID = -5A
    RDS(ON)(Typ.)38mΩ @ VGS =-10V
    RDS(ON)(Typ.)58mΩ @ VGS =-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX4606应用:
    PWM applications
    Load switch
    Power management

    MX4606典型应用及引脚:
