N+P-MOS

PE4025KC TO252-4L

    PE4025KC是N-Channel:VDS=40V,ID=16A,RDS(ON)<18mΩ,@VGS=10V,RDS(ON)<25mΩ,@VGS=4.5V.P-Channel:VDS=-40V,ID=-13A,RDS(ON)<32mΩ,@VGS=-10V,RDS(ON)<48mΩ,@VGS=-4.5V的N and P Channel Enhancement Mode Power MOSFET.
    PE4025KC的丝印是PE4025KC.PE4025KC提供TO-252-4L封装.
    The PE4025KC uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE4025KC概述:
        PE4025KC是N-Channel:VDS=40V,ID=16A,RDS(ON)<18mΩ,@VGS=10V,RDS(ON)<25mΩ,@VGS=4.5V.P-Channel:VDS=-40V,ID=-13A,RDS(ON)<32mΩ,@VGS=-10V,RDS(ON)<48mΩ,@VGS=-4.5V的N and P Channel Enhancement Mode Power MOSFET.PE4025KC的丝印是PE4025KC.PE4025KC提供TO-252-4L封装.
        The PE4025KC uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE4025KC特性:
    N-Channel
    VDS = 40V, ID = 16A
    RDS(ON) < 18mΩ @ VGS=10V
    RDS(ON) < 25mΩ @VGS=4.5V
    P-Channel
    VDS = -40V, ID = -13A
    RDS(ON) < 32mΩ @ VGS=-10V
    RDS(ON) < 48mΩ @VGS=-4.5V
    High Power and current handingcapability
    Lead free product is acquired
    Surface Mount Package

    PE4025KC应用:
    DC motor
    PWM applications

    PE4025KC典型应用及引脚图:
