PE7204A概述：
PE7204A是VDS=-20V,ID=-4.1A，RDS(ON)<45mΩ，@VGS=-4.5V，RDS(ON)<60mΩ，@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET.
PE7204A的丝印是7204A.PE7204A提供SOT-23封装.
PE7204A的丝印是7204A.PE7204A提供SOT-23封装.
The PE7204A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE7204A特性：
PE7204A特性：
VDS = -20V, ID = -4.1A
RDS(ON) < 45mΩ @VGS=-4.5V
RDS(ON) < 60mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE7204A应用：
PE7204A应用：
PWM applications
Load switch
Power management
PE7204A典型应用及引脚：
PE7204A典型应用及引脚：
