S-P-MOS

MX4435 SOP8

    MX4435是VDS=-30V,ID =-8A,RDS(ON)(Typ.)20m?,@VGS=-10V,RDS(ON)(Typ.)30m?,@VGS=-4.5V的P-Channel MOSFET.
    MX4435提供SOP-8封装.

    The MX4435 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 4.5V.

    MX4435概述:
        MX4435是VDS=-30V,ID =-8A,RDS(ON)(Typ.)20m?,@VGS=-10V,RDS(ON)(Typ.)30m?,@VGS=-4.5V的P-Channel MOSFET.
        MX4435提供SOP-8封装.
        The MX4435 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 4.5V.

    MX4435特性:

    VDS = -30V,ID = -8A
    RDS(ON) (Typ.)20m? @ VGS=-10V
    RDS(ON) (Typ.)30m? @ VGS=-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX4435应用:
    PWM applications
    Load switch
    Power management

    MX4435典型应用及引脚图:
