ChipSourceTek Take you to know the precautions for the use of CST6118 chip
Time:2021-11-18
Views:2521
ChipSourceTek takes you to know the precautions for the use of CST6118 chip:
1. It is generally recommended to add 104 capacitor from CST6118 power supply to ground. If the power supply fluctuates greatly or the output driving current is large, it is recommended to add 10uf-330uf electrolytic capacitor, which can be selected according to the actual situation.
2. The general application of CST6118 can omit the C2 and C3 capacitors connected at the output terminal. If the power fluctuation is large or the output driving current is large, it is recommended to add capacitors C2 and C3.
3. CST6118 is sensitive to static electricity. Anti static measures shall be taken in the process of packaging, transportation and processing.
