单N-MOS

PE8306A SOT23

    PE8306A是VDS=30V,ID=6A,RDS(ON)<28mΩ@VGS=10V,RDS(ON)<35mΩ@VGS=4.5V,RDS(ON)<52mΩ@VGS=2.5V的N沟道MOSFET。
    PE8306A的丝印是8306A。PE8306A提供SOT-23封装。
    The PE8306A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE8306A概述:
        PE8306A是VDS=30V,ID=6A,RDS(ON)<28mΩ@VGS=10V,RDS(ON)<35mΩ@VGS=4.5V,RDS(ON)<52mΩ@VGS=2.5V的N沟道MOSFET。
        PE8306A的丝印是8306A。PE8306A提供SOT-23封装。
        The PE8306A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE8306A特性:
    VDS = 30V, ID = 6A
    RDS(ON) < 28mΩ @ VGS=10V
    RDS(ON) < 35mΩ @ VGS=4.5V
    RDS(ON) < 52mΩ @ VGS=2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE8306A应用:
    PWM applications
    Load switch
    Power management

    PE8306A典型应用及引脚:
