单N-MOS

PE6058S SOP8

    PE6058S是VDS=60V,ID=10A,RDS(ON)<16mΩ,@VGS=10V,RDS(ON)<20mΩ,@VGS=4.5V的N-Channel MOSFET.
    PE6058S的丝印是PE6058S.PE6058S提供SOP-8封装.
    The PE6058S uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE6058S概述:
        PE6058S是VDS=60V,ID=10A,RDS(ON)<16mΩ,@VGS=10V,RDS(ON)<20mΩ,@VGS=4.5V的N-Channel MOSFET.PE6058S的丝印是PE6058S.PE6058S提供SOP-8封装.
        The PE6058S uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE6058S特性:
    VDS = 60V, ID = 10A
    RDS(ON) < 16mΩ @ VGS=10V
    RDS(ON) < 20mΩ @ VGS=4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE6058S应用:
    PWM applications
    Load switch
    Power management

    PE6058S典型应用及引脚:
