单N-MOS

PE2302A SOT23

    PE2302A是VDS=20V,ID=3A,RDS(ON)<45mΩ,@VGS=4.5V,RDS(ON)<55mΩ,@VGS=2.5V的N-Channel MOSFET.
    PE2302A的丝印是b.NC3A.PE2302A提供SOT-23封装.
    The PE2302A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE2302A概述:
        PE2302A是VDS=20V,ID=3A,RDS(ON)<45mΩ,@VGS=4.5V,RDS(ON)<55mΩ,@VGS=2.5V的N-Channel MOSFET.
        PE2302A的丝印是b.NC3A.PE2302A提供SOT-23封装.
        The PE2302A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE2302A特性:

    VDS = 20V, ID =3A
    RDS(ON) < 45mΩ @VGS=4.5V
    RDS(ON) < 55mΩ@VGS=2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE2302A应用:

    PWM applications
    Load switch

    PE2302A典型应用及引脚:
