单N-MOS

MX2316 SOT23

    MX2316是VDS=20V,ID=6A,RDS(ON)(Typ.)=21mΩ,@VGS=2.5V,RDS(ON)(Typ.)=16mΩ,@VGS=4.5V的N沟道MOSFET.
    MX2316提供SOT-23封装.
    The MX2316 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a battery protection or in other switching application.

    MX2316概述:
       MX2316是VDS=20V,ID=6A,RDS(ON)(Typ.)=21mΩ,@VGS=2.5V,RDS(ON)(Typ.)=16mΩ,@VGS=4.5V的N沟道MOSFET.
       MX2316提供SOT-23封装.
       The MX2316 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a battery protection or in other switching application.

    MX2316特性:

    VDS=20V, ID=6A
    RDS(ON)(Typ.)=21mΩ @ VGS=2.5V
    RDS(ON)(Typ.)=16mΩ @ VGS=4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    MX2316应用:

    Battery protection
    Load switch
    Power management

    MX2316订购信息:

    Part Number

    StorageTemperature

    Package

    Devices Per Reel

    MX2316

    -55°C to 150°C

    SOT-23

    3000


    MX2316典型应用及封装图:
