单N-MOS

MX2300C SOT23

    MX2300C是VDS=20V,ID=2.5A,RDS(ON)(Typ.)52mΩ@Vgs=4.5V,RDS(ON)(Typ.)72mΩ@Vgs=2.5V的N沟道MOSFET.
    MX2300C的丝印是A2sHB.MX2300C提供SOT23封装.
    The MX2300C uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.
    This device is suitable for use as a load switch or in PWM applications.
    MX2300C概述:
        MX2300C是VDS=20V,ID=2.5A,RDS(ON)(Typ.)52mΩ@Vgs=4.5V,RDS(ON)(Typ.)72mΩ@Vgs=2.5V的N沟道MOSFET.
        MX2300C的丝印是A2sHB.MX2300C提供SOT23封装.
        The MX2300C uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.
        This device is suitable for use as a load switch or in PWM applications.

    MX2300C特性:
    VDS=20V,ID=2.5A
    RDS(ON)(Typ.)52mΩ@Vgs=4.5V
    RDS(ON)(Typ.)72mΩ@Vgs=2.5V
    High power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX2300C应用:
    PWM applications
    Load switch
    Power management

    MX2300C典型应用及引脚图:
