单N-MOS

CST50N03 TO252

    CST50N03是VDS=30V,REDSON=7.6mΩ,ID=50A的N沟道Mosfet,封装是TO252。
    The CST50N03 is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
    The CST50N03 meet the RoHS and Green Product requirement, 100% EAS guaranteed with full function reliability approved.
    CST50N03 Description:
        CST50N03是VDS=30V,REDSON=7.6mΩ,ID=50A的N沟道Mosfet,封装是TO252。
        The CST50N03 is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
        The CST50N03 meet the RoHS and Green Product requirement, 100% EAS guaranteed with full function reliability approved.

    CST50N03 Features:
    Super Low Gate Charge
    100% EAS Guaranteed
    Green Device Available
    Excellent CdV/dt effect decline
    Advanced high cell density Trench technology

    CST50N03 TO252 Pin Configuration:

    CST50N03 Product Summary:

    BVDSS
    RDSON
    ID
    30V
    7.6mΩ
    50A
    CST50N03 Test Circuit:
