单N-MOS

CST30N03B PRPAK3*3

    CST30N03B是BVDSS=30V,RDSON=9.5mΩ,ID=25A的N沟道快速切换mosfets。提供PRPAK3*3封装。
    The CST30N03B is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
    The CST30N03B meet the RoHS and Green Product requirement, 100% EAS guaranteed with full function reliability approved.
    CST30N03B Description/描述:
        CST30N03B 是BVDSS=30V,RDSON=9.5mΩ,ID=25A的N沟道快速切换mosfets。提供PRPAK3*3封装。
        The CST30N03B is the high cell density trenched N-ch MOSFETs, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
        The CST30N03B meet the RoHS and Green Product requirement, 100% EAS guaranteed with full function reliability approved.

    CST30N03B Features/特性:
    Green Device Available
    Super Low Gate Charge
    Excellent CdV/dt effect decline
    Advanced high cell density Trench technology

    CST30N03B Product Summary/产品概览:
    BVDSS
    RDSON
    ID

    30V

    9.5mΩ

    25A


    CST30N03B PRPAK3*3 Pin Configuration//引脚配置:

    CST30N03B Test Circuit/测试电路:
