单P-MOS

PE3401A SOT23

    PE3401A是VDS=-30V,ID=-4.2A,RDS(ON)<50mΩ,@VGS=-10V,RDS(ON)<65mΩ,@VGS=-4.5V,RDS(ON)<100mΩ,@VGS=-2.5V的P-Channel MOSFET.
    PE3401A提供SOT-23封装.
    The PE3401A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE3401A概述:
        PE3401A是VDS=-30V,ID=-4.2A,RDS(ON)<50mΩ,@VGS=-10V,RDS(ON)<65mΩ,@VGS=-4.5V,RDS(ON)<100mΩ,@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET.
        PE3401A提供SOT-23封装.
        The PE3401A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE3401A特性:
    VDS = -30V, ID = -4.2A
    RDS(ON) < 50mΩ@ VGS=-10V
    RDS(ON) < 65mΩ@VGS=-4.5V
    RDS(ON) < 100mΩ@VGS=-2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE3401A应用:
    PWM applications
    Load switch
    Power management

    PE3401A典型应用及引脚:
