当前位置:网站首页 >> 产品中心 >> Mosfet >> 单P-MOS

单P-MOS

PE30P13DS SOP8

    PE30P13DS是VDS=-30V,ID=-9A,RDS(ON)<17mΩ,@VGS=-10V,RDS(ON)<25mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
    PE30P13DS的丝印是PE30P13DS.PE30P13DS提供SOP-8封装.
    The PE30P13DS uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE30P13DS概述:
        PE30P13DS是VDS=-30V,ID=-9A,RDS(ON)<17mΩ,@VGS=-10V,RDS(ON)<25mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE30P13DS的丝印是PE30P13DS.PE30P13DS提供SOP-8封装.
        The PE30P13DS uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE30P13DS特性:
    VDS = -30V, ID = -9A
    RDS(ON) < 17mΩ @ VGS=-10V
    RDS(ON) < 25mΩ @VGS=-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE30P13DS应用:
    PWM applications
    Load switch
    Power management

    PE30P13DS典型应用及引脚图:

    请提交您的基本信息,发邮件Sales@ChipSourceTek.com,或者打电话给我们,13823761625(微信同号),我们将会尽快与您联系!

    *

    *

    *

    *
