单P-MOS

PE7304AH SOT23

    PE7304AH是VDS=-30V,ID=-4A,RDS(ON)<52mΩ,@VGS=-10V,RDS(ON)<85mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
    PE7304AH的丝印是7304AH.PE7304AH提供SOT-23封装.
    The PE7304AH uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE7304AH概述:
        PE7304AH是VDS=-30V,ID=-4A,RDS(ON)<52mΩ,@VGS=-10V,RDS(ON)<85mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE7304AH的丝印是7304AH.PE7304AH提供SOT-23封装.
        The PE7304AH uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE7304AH特性:
    VDS = -30V, ID = -4A
    RDS(ON) < 52mΩ @ VGS=-10V
    RDS(ON) < 85mΩ @VGS=-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE7304AH应用:
    PWM applications
    Load switch
    Power management

    PE7304AH典型应用及引脚:
