单P-MOS

PE4953 SOP8

    PE4953是VDS=-30V,ID=-5.3A,RDS(ON)<49mΩ,@VGS=-10V,RDS(ON)<85mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
    PE4953的丝印是PE4953.PE4953提供SOP-8封装.
    The PE4953 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE4953概述:
        PE4953是VDS=-30V,ID=-5.3A,RDS(ON)<49mΩ,@VGS=-10V,RDS(ON)<85mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE4953的丝印是PE4953.PE4953提供SOP-8封装.
        The PE4953 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE4953特性:
    VDS = -30V, ID = -5.3A
    RDS(ON) < 49mΩ @ VGS=-10V
    RDS(ON) < 85mΩ @VGS=-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE4953应用:
    PWM applications
    Load switch
    Power management

    PE4953典型应用及引脚图:

    请提交您的基本信息,发邮件Sales@ChipSourceTek.com,或者打电话给我们,13823761625(微信同号),我们将会尽快与您联系!

    *

    *

    *

    *
