单P-MOS

PE4407A SOP8

    PE4407A是VDS=-30V,ID=-12A,RDS(ON)<13mΩ,@VGS=-10V,RDS(ON)<19mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
    PE4407A的丝印是PE4407A.PE4407A提供SOP8封装.
    The PE4407A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE4407A概述:
        PE4407A是VDS=-30V,ID=-12A,RDS(ON)<13mΩ,@VGS=-10V,RDS(ON)<19mΩ,@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.
        PE4407A的丝印是PE4407A.PE4407A提供SOP8封装.
        The PE4407A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE4407A特性:
    VDS = -30V, ID = -12A
    RDS(ON) < 13mΩ @ VGS=-10V
    RDS(ON) < 19mΩ @VGS=-4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE4407A应用:
    PWM applications
    Load switch
    Power management

    PE4407A典型应用及引脚:
