PE15D11概述:
PE15D11是VDS=-18V,ID=-7A,RDS(ON)<23m?,@VGS=-4.5V,RDS(ON)<30m?,@VGS=-2.5V的P-Channel MOSFET.PE15D11提供TSSOP-8封装.
The PE15D11 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE15D11特性:
VDS = -18V, ID = -7A
RDS(ON) < 23m? @VGS=-4.5V
RDS(ON)< 30m? @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE15D11应用:
PWM applications
Load switch
Power management
PE15D11典型应用及引脚排列:
