单P-MOS

PE2301 SOT-23

    PE2301是VDS=-20V,ID=-3A,RDS(ON)<110mΩ,@VGS=-4.5V,RDS(ON)<140mΩ,@VGS=-2.5V的P-Channel MOSFET.
    PE2301的丝印是a.NC3A.PE2301提供SOT-23封装.
    The PE2301 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE2301概述:
        PE2301是VDS=-20V,ID=-3A,RDS(ON)<110mΩ,@VGS=-4.5V,RDS(ON)<140mΩ,@VGS=-2.5V的P-Channel MOSFET.
        PE2301的丝印是a.NC3A.PE2301提供SOT-23封装.
        The PE2301 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE2301特性:

    VDS = -20V, ID = -3A
    RDS(ON) < 110mΩ @VGS=-4.5V
    RDS(ON) < 140mΩ @VGS=-2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE2301应用:

    PWM applications
    Load switch
    Power management

    PE2301典型应用及引脚图:
