MX8205A是VDS=20V,ID=6A，RDS(ON)(Typ.)=27mΩ@VGS=2.5V，RDS(ON)(Typ.)=22mΩ@VGS=3.8V，RDS(ON)(Typ.)=21mΩ@VGS=4.5V的双N沟道Mosfet.

The MX8205A uses advanced trench technology to provide excellent RDS(ON) and low gate charge.It can be used in a wide variety of applications.

MX8205A 描述/Description：

MX8205A是VDS=20V,ID=6A，RDS(ON)(Typ.)=27mΩ@VGS=2.5V，RDS(ON)(Typ.)=22mΩ@VGS=3.8V，RDS(ON)(Typ.)=21mΩ@VGS=4.5V的双N沟道Mosfet.

The MX8205A uses advanced trench technology to provide excellent RDS(ON) and low gate charge.It can be used in a wide variety of applications.

MX8205A 特性/Features：

--VDS=20V, ID=6A

RDS(ON)(Typ.)=27mΩ @ VGS=2.5V

RDS(ON)(Typ.)=22mΩ @ VGS=3.8V

RDS(ON)(Typ.)=21mΩ @ VGS=4.5V

--High Power and current handing cpability

--Lead free product is acquired

--Surface Mount Package

--Battery protection

--Load switch

MX8205A 引脚分配/Pinout：

MX8205A 订购信息/Ordering Information：

Part Number	StorageTemperature	Package	Devices Per Reel
MX8205A	-55°C to 150°C	TSSOP-8	5000
