PE3401概述：
PE3401是VDS=-30V,ID=-4.2A，RDS(ON)<50mΩ，@VGS=-10V，RDS(ON)<65mΩ,@VGS=-4.5VRDS(ON)<90mΩ,@VGS=-2.5V的P-Channel MOSFET.
PE3401提供SOT-23-3L封装.
PE3401提供SOT-23-3L封装.
The PE3401 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE3401特性：
VDS = -30V, ID = -4.2A
RDS(ON) < 50mΩ @ VGS=-10V
RDS(ON) < 65mΩ @VGS=-4.5V
RDS(ON) < 90mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE3401应用：
PWM applications
Load switch
Power management
PE3401典型应用及引脚：
