S-P-MOS

MX3401 SOT23-3

     MX3401是VDS=-30V,ID=-4.4A,RDS(ON)(Typ.)=50m,@VGS=-10V,RDS(ON)(Typ.)=40m,@VGS=-4.5V,RDS(ON)(Typ.)=47m,@VGS=-2.5V,RDS(ON)(Typ.)=68m的P沟道MOSFET.
    MX3401提供SOT-23-3L封装.
    The MX3401 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a load switch or in PWM applications

    MX3401概述:
        MX3401是VDS=-30V,ID=-4.4A,RDS(ON)(Typ.)=50m,@VGS=-10V,RDS(ON)(Typ.)=40m,@VGS=-4.5V,RDS(ON)(Typ.)=47m,@VGS=-2.5V,RDS(ON)(Typ.)=68m的P沟道MOSFET.
        MX3401提供SOT-23-3L封装.
        The MX3401 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a load switch or in PWM applications.

    MX3401特性:

    VDS =-30V,ID =-4.4A
    RDS(ON)(Typ.)=50m
    @VGS=-10V RDS(ON)(Typ.)=40m
    @VGS=-4.5V RDS(ON)(Typ.)=47m
    @VGS=-2.5V RDS(ON)(Typ.)=68m
    High power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX3401应用:

    PWM applications
    Load switch

    MX3401订购信息:

    Part Number

    Marking

    StorageTemperature

    Package

    Devices Per Reel

    MX3401

    E.NC3A

    -55°C to +150°C

    SOT-23-3L

    3000


    MX3401典型应用及引脚图:
