单N-MOS

MX3400A SOT23

    MX3400A是VDS=30V,ID=5.8A,RDS(ON)(Typ.)22m@,Vgs=10V,RDS(ON)(Typ.)25m,@Vgs=4.5V,RDS(ON)(Typ.)30m,@Vgs=2.5V的N沟道MOSFET.
    MX3400A的丝印是f.NC.MX3400A提供SOT-23封装.
    The MX3400A uses advanced trenchtechnology to provide excellent RDS(ON), low gatecharge and operation with gate voltages as lowas 2.5V.
    This device is suitable for use as a load switch orin PWM applications.

    MX3400A概述:
        MX3400A是VDS=30V,ID=5.8A,RDS(ON)(Typ.)22m@,Vgs=10V,RDS(ON)(Typ.)25m,@Vgs=4.5V,RDS(ON)(Typ.)30m,@Vgs=2.5V的N沟道MOSFET.
        MX3400A的丝印是f.NC.MX3400A提供SOT-23封装.
        The MX3400A uses advanced trenchtechnology to provide excellent RDS(ON), low gatecharge and operation with gate voltages as lowas 2.5V.
        This device is suitable for use as a load switch orin PWM applications.

    MX3400A特性:

    VDS =30V,ID =5.8
    RDS(ON)(Typ.)22m @ Vgs=10V
    RDS(ON)(Typ.)25m @ Vgs=4.5V
    RDS(ON)(Typ.)30m @ Vgs=2.5V
    High power and current handing capability
    Lead free product is acquired
    Surface mount package

    MX3400A应用:

    PWM applications
    Load switch

    MX3400A典型应用及引脚图:
