单N-MOS

PE3400A SOT23

    PE3400A是VDS=30V,ID=5.8A,RDS(ON)<35mΩ,@VGS=10V,RDS(ON)<40mΩ,@VGS=4.5V,RDS(ON)<55mΩ,@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.
    PE3400A的丝印是f.NC.PE3400A提供SOT-23封装.
   The PE3400A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE3400A概述:
        PE3400A是VDS=30V,ID=5.8A,RDS(ON)<35mΩ,@VGS=10V,RDS(ON)<40mΩ,@VGS=4.5V,RDS(ON)<55mΩ,@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE3400A的丝印是f.NC.PE3400A提供SOT-23封装.
        The PE3400A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE3400A特性:
    VDS = 30V, ID = 5.8A
    RDS(ON) < 35mΩ@ VGS=10V
    RDS(ON) < 40mΩ @VGS=4.5V
    RDS(ON) < 55mΩ@VGS=2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE3400A应用:
    PWM applications
    Load switch
    Power management

    PE3400A典型应用及引脚:
