单P-MOS

PE7280G DFN5x6-8L

    PE7280G是VDS=-20V,ID=-80A,RDS(ON)<6mΩ,@VGS=-10V,RDS(ON)<7.2mΩ,@VGS=-4.5V,RDS(ON)<11.2mΩ,@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET
    PE7280G的丝印是PE7280G.PE7280G提供DFN5x6-8L封装.
    The PE7280G uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
    PE7280G概述:
        PE7280G是VDS=-20V,ID=-80A,RDS(ON)<6mΩ,@VGS=-10V,RDS(ON)<7.2mΩ,@VGS=-4.5V,RDS(ON)<11.2mΩ,@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET
        PE7280G的丝印是PE7280G.PE7280G提供DFN5x6-8L封装.
        The PE7280G uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE7280G特性:
    VDS = -20V, ID = -80A
    RDS(ON) < 6mΩ @ VGS=-10V
    RDS(ON) < 7.2mΩ @ VGS=-4.5V
    RDS(ON) < 11.2mΩ @VGS=-2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE7280G应用:
    PWM applications
    Load switch
    Power management

    PE7280G典型应用及引脚:
