单P-MOS

MX3407A SOT23

    MX3407A是VDS =-30V,ID =-4.3A,RDS(ON)(Typ.) 54mΩ@VGS=-4.5V,RDS(ON)(Typ.) 38mΩ@VGS=-10V的P沟道MOS.
    MX3407A提供SOT23封装.
    TheMX3407A usesadvanced trench technology to provide excellent RDS(ON), This device is suitable for use as a load switch or in PWM applications.
    MX3407A概述:
        MX3407A是VDS =-30V,ID =-4.3A,RDS(ON)(Typ.) 54mΩ@VGS=-4.5V,RDS(ON)(Typ.) 38mΩ@VGS=-10V的P沟道MOS.
        MX3407A提供SOT23封装.
        TheMX3407A usesadvanced trench technology to provide excellent RDS(ON), This device is suitable for use as a load switch or in PWM applications.

    MX3407A特性:
    VDS =-30V,ID =-4.3A
    RDS(ON)(Typ.) 54mΩ@VGS=-4.5V
    RDS(ON)(Typ.) 38mΩ@VGS=-10V
    High power and current handing capability
    Lead free product is acquired
    Surface mount package
    MX3407A提供SOT23封装

    MX3407A应用:
    PWM applications
    Load switch
    Power

    MX3407A应用图:
