双N-MOS

JL8205A TSSOP-8

    JL8205A是VDS=20V,ID=6A,RDS(ON)<34mΩ@VGS=2.5V,RDS(ON)<24mΩ@VGS=4.5V的N沟道MOSFET.JL8205A提供TSSOP-8封装.
    The JL8205A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V.
    This device is suitable for use as a Battery protection or in other Switching application.
    JL8205A概述:
        JL8205A是VDS=20V,ID=6A,RDS(ON)<34mΩ@VGS=2.5V,RDS(ON)<24mΩ@VGS=4.5V的N沟道MOSFET.JL8205A提供TSSOP-8封装.
        The JL8205A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a Battery protection or in other Switching application.

    JL8205A特性:
    VDS=20V,ID=6A
    RDS(ON)<34mΩ@VGS=2.5V
    RDS(ON)<24mΩ@VGS=4.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    JL8205A应用:
    Battery protection
    Load switch
    Power management

    JL8205A订购信息:
    Device Marking
    Device
    Device Package
    Reel Size
    Tape width
    Quantity
    8205A
    JL8205A
    TSSOP-8
    Ø330mm
    12mm
    3000 units

    JL8205A原理图及封装图:
