单P-MOS

PE2305A SOT23

    PE2305A是VDS=-20V,ID=-4.1A,RDS(ON)<45mΩ,@VGS=-4.5V,RDS(ON)< 60mΩ,@VGS=-2.5V的P-Channel MOSFET.
    PE2305A提供SOT-23封装.
    The PE2305A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE2305A概述:
        PE2305A是VDS=-20V,ID=-4.1A,RDS(ON)<45mΩ,@VGS=-4.5V,RDS(ON)< 60mΩ,@VGS=-2.5V的P-Channel MOSFET.PE2305A提供SOT-23封装.
        The PE2305A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

    PE2305A特性:

    VDS = -20V, ID = -4.1A
    RDS(ON) < 45mΩ @VGS=-4.5V
    RDS(ON) < 60mΩ @VGS=-2.5V
    High Power and current handing capability
    Lead free product is acquired
    Surface Mount Package

    PE2305A应用:

    PWM applications
    Load switch
    Power management

    PE2305A典型应用及引脚:
