单P-MOS

MX2305 SOT23-3

   MX2305是VDS=-20V,ID=-4A,RDS(ON)(Typ.)<38mΩ@VGS=-4.5V,RDS(ON)(Typ.)< 54mΩ@VGS=-2.5V的N沟道MOS.
    MX2305的丝印是3415E.MX2305提供SOT23-3封装。
    The MX2305 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gatevoltages as low as1.8V. This device is suitable for use as a load switch or in PWM applications .It is ESD protected.
    MX2305概述:
       MX2305是VDS=-20V,ID=-4A,RDS(ON)(Typ.)<38mΩ@VGS=-4.5V,RDS(ON)(Typ.)< 54mΩ@VGS=-2.5V的N沟道MOS.
        MX2305的丝印是3415E.MX2305提供SOT23-3封装。
        The MX2305 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gatevoltages as low as1.8V. This device is suitable for use as a load switch or in PWM applications .It is ESD protected.

    MX2305特性:
    VDS =-20V,ID =-4A
    RDS(ON)(Typ.) < 38mΩ @ VGS=-4.5V
    RDS(ON) (Typ.)< 54mΩ @ VGS=-2.5V
    ESD Rating: 2500V HBM
    High Power and current handing capability
    Lead free product is acquired
    Surface mount package
    MX2305提供SOT23-3封装

    MX2305应用市场:
    PWM applications
    Load switch

    MX2305应用图:
